SME M2-12R

SPECIFICATIONS Distance from pivot to stylus 308.81mm Effective mass 18.0g Distance from pivot to turntable centre 295.60mm Cartridge balance range Up to 38.0g (S2-R headshell) Up to 46.0g (Plug-in heads) Cartridge fixing centres 12.70mm Vertical tracking force VTF up to 5.0g Offset angle 17.62° Maximum tracking error 0.01°/mm Linear offset 93.47mm Null points Inner 66.04mm Outer 120.90mm Overhang 13.21mm Weight net 834.0g Height above mounting surface max. 87.0mm min. 63.0mm Audio lead 1.2m balanced hybrid cable with gold plated connectors Mounting surface to underside of headshell max. 69.75mm min. 45.75mm Depth below mounting surface 46.0mm Balance weight radial clearance 85.0mm
